Music Hall - Spirit Cartdridge (Fonocaptor)

The music hall Spirit is a supremely musical, moving magnet phono cartridge.

    Developed and built specially for Music Hall by Audio Technica, this little gem incorporates a low-mass cantilever and an elliptical stylus tip that gets down deep into the grooves (pun intended) and sets the music free.

The Spirit is as easy to use as it is compatible, performing admirably with a wide range of tonearms and turntables. Built for longevity, it features a user-replaceable stylus.

frequency response    20Hz – 20kHz ± 3dB
channel balance    2.5dB @ 1kHz
channel separation    >20dB @ 1kHz
output    3.5mV ± 2dB, 1kHz @ 5cm/sec
vertical tracking angle    20 degrees
stylus shape    elliptical 0.4 x 0.7 mil
stylus type    replaceable
cantilever    alloy tube
load impedance    47,000 Ohm
stylus construction    bonded round shank
cartridge weight    5.7g
fixing center    0.5” (12.7mm)
playing weight    1.5 – 2.5g (2.0g nom.)
